Description
The Daikin FXAQ63A is a stylish VRV wall mounted indoor unit designed to provide efficient cooling and heating, quiet operation, and comfortable air distribution. Its flat front panel blends smoothly with modern interior décor, making it suitable for villas, apartments, offices, hotel rooms, retail areas, and commercial interiors. ❄️
Key Features
| Feature | Description |
|---|---|
| Brand | Daikin |
| Model | FXAQ63A |
| Series | FXAQ-A |
| Product Type | VRV wall mounted indoor unit |
| Installation Type | Wall mounted |
| Cooling Capacity | 7.1 kW |
| Heating Capacity | 8.0 kW |
| Power Supply | 1-phase, 220V / 240V, 50 Hz |
| Casing Colour | White |
| Refrigerant | R-410A |
| Sound Pressure Level | 46.5 / 38.5 dB(A) cooling |
| Application | Homes, villas, apartments, hotel rooms, offices, and commercial interiors |
Product Features
| Feature | Details |
|---|---|
| Stylish Flat Front Panel | The clean and modern front panel blends easily with different interior styles. |
| Easy Cleaning | The smooth surface can be cleaned easily, helping maintain a neat appearance. |
| Cooling & Heating Operation | Provides both cooling and heating performance for year-round comfort. |
| DC Fan Motor | Specially developed DC fan motor helps reduce energy consumption. |
| Vertical Auto-Swing | Distributes air up and down for more even room comfort. |
| Five Discharge Angles | Airflow direction can be programmed through the remote controller. |
| Quiet Operation | Designed for low sound operation, making it suitable for bedrooms, offices, and hotel rooms. |
| Fan Only Operation | Can operate as a fan without cooling or heating. |
| Dry Programme | Helps reduce humidity without major room temperature variation. |
| Auto Cooling / Heating Changeover | Automatically selects cooling or heating mode to reach the set temperature. |
| Home Leave Operation | Maintains indoor temperature at a selected comfort level during absence while saving energy. |
| Easy Front Maintenance | Maintenance operations can be performed from the front of the unit. |
| Auto Restart Function | Restarts automatically with original settings after a power failure. |
| Self-Diagnosis Function | Simplifies maintenance by indicating system faults or operating anomalies. |
| Remote Control Options | Compatible with infrared and wired remote controller options. |
| Centralised Control Support | Can be connected to a centralised control system for easier management of multiple units. |
| Optional Drain Pump Kit | Optional drain pump kit supports easier condensation drainage from the indoor unit. |
Technical Parameters
| Specification | Details |
|---|---|
| Model | FXAQ63A |
| Cooling Capacity | 7.1 kW |
| Heating Capacity | 8.0 kW |
| Power Input Cooling | 0.05 kW |
| Power Input Heating | 0.06 kW |
| Dimensions H × W × D | 290 × 1,050 × 269 mm |
| Machine Weight | 15 kg |
| Casing | White |
| Airflow Rate Cooling High / Low | 18.3 / 13.5 m³/min |
| Air Filter Type | Washable resin net |
| Sound Power Level Cooling | 63.0 dB(A) |
| Sound Pressure Level Cooling High / Low | 46.5 / 38.5 dB(A) |
| Sound Pressure Level Heating High / Low | 47.0 / 38.5 dB(A) |
| Refrigerant Type | R-410A |
| GWP | 2087.5 |
| Liquid Pipe Connection OD | 9.52 mm |
| Gas Pipe Connection OD | 15.9 mm |
| Drain Connection | VP13, I.D. 15 mm / O.D. 18 mm |
| Power Supply | 1-phase, 50 Hz, 220–240V |
| Maximum Fuse Amps | 16 A |
| Infrared Remote Control | BRC7EA628 / BRC7EA629 |
| Wired Remote Control | BRC1H51W / S / K, BRC1E53A / B / C |
Application Scope
| Application Area | Details |
|---|---|
| Villas & Apartments | Suitable for bedrooms, living rooms, and premium residential interiors. |
| Hotel Rooms | Provides quiet cooling and heating with a clean wall mounted appearance. |
| Offices | Ideal for private offices, meeting rooms, and workspaces. |
| Retail Spaces | Suitable for shops, showrooms, and customer-facing areas. |
| Commercial Interiors | Works well where wall mounted VRV indoor cooling and heating are required. |
| Refurbishment Projects | Can be installed in both new and refurbishment projects due to its simple wall mounted design. |
Main Benefits
- Stylish VRV wall mounted indoor unit
- Cooling capacity of 7.1 kW
- Heating capacity of 8.0 kW
- Clean flat front panel for modern interiors
- Quiet indoor operation
- DC fan motor for improved energy efficiency
- Vertical auto-swing for better air distribution
- Fan only and dry operation modes
- Auto cooling / heating changeover
- Easy front maintenance
- Remote control and centralised control compatibility
- Optional drain pump kit support ⚙️
