LZS Engine Tachometer Automobile Engine

F A J Trading LLC

Model: RM-1000
Measurement Type: Non-Contact Photoelectric / Laser Electronic Measurement
Measuring Range: 10 to 100,000 RPM
Memory Function: Max / Min Memory
Measurement Method: Direct Beam Set-Beam Measurement
Application: Machinery Industry and Rotating Equipment
Display: Digital LCD Display
Operation Buttons: HOLD, START, RECALL, and Power Switch
Design: Portable Handheld Tachometer

Fast Delivery

Buy Now Pay Later

Secure Payments

Trusted Quality

Quantity must be 1 or more

Notify me when back in stock

Description

Main Function

Used to measure the speed/RPM of diesel and gasoline engines in real time. The instrument is controlled by a microcomputer and displays the engine speed on a liquid crystal display.

Key Features

Feature	Details
Product Name	LZS Engine Tachometer
Application	Diesel engine and gasoline engine speed measurement
Display	Liquid crystal display / LCD
Control System	Microcomputer controlled
Measurement Type	Real-time engine speed measurement
Test Range	0 to 9999 RPM
Power Supply	Single 9V battery
Sensor System	Separate sensor connected to main unit
Operating Method	Gasoline engine and diesel engine testing modes

Operating Environment

Parameter	Specification
Ambient Temperature	-15°C to 45°C
Relative Humidity	20% to 80%

Product Structure

The instrument consists of two main parts:

Main Machine / Tachometer Unit
Sensor Part

The sensor is connected to the right side of the instrument through a connector.

Engine Testing Method

1. Gasoline Engine Testing

Pull out the antenna on the upper part of the tachometer.
Place it at any position of the engine.
Can be used in contact or non-contact state.
Start the engine.
Turn on the power switch.
The instrument displays the engine speed in real time.

2. Diesel Engine Testing

Attach the diesel engine speed sensor to the high-pressure oil pipe of the diesel engine.
Start the engine.
After normal engine operation, turn on the power switch.
The instrument displays the engine speed in real time.

Adjustment Note

Due to different pressures in diesel engine high-pressure tubing, the instrument includes two gain adjustment modes. If the displayed speed is unstable, adjust the gain switch on the right side of the instrument panel.
